Cudy GS2008S2 8-Port Managed Switch

The GS2008S2 is an 8-Port Gigabit L2 Managed PoE+ Switch with 2 SFP Slots. It is designed to provide power and network connectivity to PoE-enabled devices such as IP cameras, VoIP phones, and wireless access points

The GS2008S2 is a high-quality and reliable switch that offers 8 Gigabit Ethernet ports with PoE+ capabilities, along with 2 Gigabit SFP slots for fiber optic connections. It also features 1 console port for management purposes.

With its 10/100/1000Mbps Ethernet ports, this switch provides fast and reliable network connectivity for your devices. It complies with the IEEE 802.3af and 802.3at standards for Power over Ethernet, delivering up to 30W of power per port. The total PoE power supply of 120W allows you to easily install and power up to 8 PoE devices.

The switch supports auto-sensing technology, which enables it to detect the power requirements of connected devices and deliver the appropriate power level. It can supply up to 30W to an 802.3at PoE+ device, while also supporting backward compatibility with 802.3af PoE devices that require 15.4W.

Built with a high-quality metal case, this switch is sturdy and durable, ensuring a long service life. It also provides excellent heat dissipation thanks to its built-in fan and venting holes, allowing for stable operation even in demanding environments.

The GS2008S2 is equipped with a high-quality TPS PoE chipset, which ensures reliable and efficient performance. It supports various network protocols, including Ethernet, Fast Ethernet, Gigabit Ethernet, and VLAN protocols. It also incorporates advanced features such as link aggregation, flow control, and access control, providing enhanced network management capabilities.

This switch offers lightning protection with electrostatic standards of 6KV contact and 8KV air, providing a safeguard against power surges. With a mean time between failures (MTBF) of over 50,000 hours, you can rely on the durability and reliability of this switch.

In terms of specifications, the GS2008S2 has a bandwidth of 20Gbps and a packet forwarding rate of 14.88Mpps. It features 128MB DDR SDRAM, 16MB flash memory, and 4M packet buffer memory. The switch supports up to 8,000 MAC addresses and up to 4,096 VLANs.

The switch is designed to operate in a wide range of environments, with an operating temperature range of -20 to 50°C and a storage temperature range of -40 to 85°C. It can function in humid conditions with operating and storage humidity ranges of 10% to 90% (non-condensing).

With its compact and rack-mountable design, the GS2008S2 is easy to install and integrate into your network infrastructure. It provides clear status indications through its LED indicators for power, system, switch, PoE, and link/activity.

The switch supports various management and maintenance options, including web management, CLI (Command Line Interface), SNMP (Simple Network Management Protocol) versions 1, 2, and 3, RMON (Remote Monitoring) version 2, and LLDP (Link Layer Discovery Protocol) device discovery. It also offers features like PoE power management, VLAN configuration, security features, QoS (Quality of Service) prioritization, and support for IPv6.
