Cudy IG1005P 5-Port Industrial PoE+ Switch

Cudy IG1005P 5-Port Industrial PoE+ Switch

The IG1005P is a 5-Port Gigabit Industrial POE+ Switch with 4 PoE ports supporting 802.3at/af standards, delivering 120W total PoE+ power. Its dual power supply support and rugged design make it an ideal choice for industrial applications, ensuring continuous operation in challenging environments.
SKU: IG1005P
Brand: Cudy
Warranty: 1 Year
UPC/EAN: 6971690792329

Arriving Soon - Expected Dispatch in 3 to 6 Weeks

Product description

Introducing the IG1005P, a high-performance 5-Port Gigabit Industrial POE+ Switch designed for the robust demands of industrial networking environments. With its powerful features and rugged design, the IG1005P is a reliable solution for powering and connecting devices in harsh industrial settings.

This switch comes equipped with four Power over Ethernet (PoE) ports, supporting the IEEE802.3at/af standards and delivering a maximum of 30W per port. The 120W total PoE+ power budget ensures ample power for connected devices, making it suitable for applications such as IP cameras, access points, and other PoE-enabled devices.

One of the standout features of the IG1005P is its dual power supply support, allowing for redundant power inputs. In the event of a power supply failure, the switch seamlessly transitions to the backup power supply, ensuring continuous operation and minimizing downtime. It's important to note that the product does not include a power adapter, allowing users to select a power source tailored to their specific needs.

Designed for versatility, the IG1005P can be conveniently mounted on DIN rails or walls, providing flexibility in deployment. Its fanless design ensures silent operation, making it ideal for noise-sensitive environments. The durable IP40 aluminum housing enhances protection against environmental challenges, while 6KV DC Ethernet ESD and EFT protection fortify the switch against electrical disturbances.

The switch features auto-sensing technology, adhering to IEEE 802.3af/at standards. This technology automatically detects connected devices and adjusts power output accordingly, preventing damage to non-standard PoE devices or standard PoE switches. The plug-and-play functionality ensures a hassle-free setup, while the high-quality metal case guarantees durability, effective heat dissipation, and a long service life.

Operating within a wide temperature range of -40ºC to 85ºC, the IG1005P excels in extreme conditions, making it suitable for industrial environments with varying temperatures. The switch's 5-port configuration includes 4 auto-MDI/MDI-X 10/100BASE-TX ports and supports a maximum bandwidth of 14Gbps, ensuring efficient data transfer.

In summary, the IG1005P is a versatile and resilient solution for industrial networks, combining PoE capabilities, dual power supply support, and robust construction. Whether in manufacturing, automation, or surveillance applications, the IG1005P delivers reliable connectivity and power, meeting the challenges of demanding industrial environments.



0.5 kgs
Number of Ports
Ports and Slots
5x RJ45 Port
Product Dimensions
12 x 9 x 4 cm
1 Year
