Ubiquiti UniFi Dream Machine Console (UDM)

Ubiquiti UniFi Dream Machine is an all-in-one network solution designed for homes and small offices. This powerful device combines various essential functions into a single sleek box, making it easy to manage your network. With its 4-core CPU, 2GB of RAM, and advanced features, the UniFi Dream Machine provides an efficient and reliable networking experience.

The UniFi Dream Machine offers a Dual Band WiFi Access Point (AP) with support for 802.11a/b/g/n/ac/ac-wave2 standards, delivering impressive speeds of up to 1733 + 300Mb/s. This ensures fast and reliable wireless connectivity throughout your space. The AP utilizes 4x4 technology for optimal performance.

In addition to the WiFi capabilities, the UniFi Dream Machine features a manageable 4-port Gigabit switch with VLAN support. This allows you to create separate virtual networks within your physical network, enhancing security and improving network efficiency. The device also includes a UniFi Security Gateway (USG) or router with advanced Intrusion Detection System (IDS), Intrusion Prevention System (IPS), and Deep Packet Inspection (DPI) functions. These features add an extra layer of protection to your network, keeping it safe from potential threats.

To manage and monitor your network, the UniFi Dream Machine comes with the UniFi Network application. This user-friendly interface allows you to easily configure and control your network settings. You can expand the capabilities of the device by adding additional UniFi switches or access points, which can be seamlessly integrated into your network using the built-in UniFi controller.

The UniFi Network and UniFi cloud apps enable remote access to your network controller from anywhere, giving you the flexibility to manage your network on the go. The device also benefits from automated software updates, ensuring that your network remains up to date and secure. Best of all, these software updates are provided free of charge.

The UniFi solution offers several advantages, including Zero Handoff Roaming, which enables uninterrupted transition between individual APs. It also supports wireless uplink, allowing you to extend your network where running data cables is not feasible. With up to 4 SSIDs (Service Set Identifiers), you can create separate networks for different purposes or user groups. The device provides detailed traffic statistics, guest network capabilities, load balancing for even client distribution, and rate limiting for each SSID.

The UniFi Dream Machine includes the device itself, a power cable, and offers various technical specifications. It operates on both 2.4GHz and 5GHz frequencies, supporting multiple WiFi standards. The device features built-in antennas with MU-MIMO technology for improved performance. It offers physical characteristics such as a compact size, a reset button, and a wide operating temperature range.

In terms of hardware, the UniFi Dream Machine is equipped with 2048MB of RAM and powered by an Arm Cortex-A57 CPU, running at a frequency of 1700MHz. It provides WAN and LAN connectivity with Gigabit speeds, ensuring fast data transfers.

The device operates as an AP router and supports IPv6. The default IP address is 192.168.1.1, and the default username and password are Ubiquiti/Ubiquiti.

With its comprehensive features, powerful performance, and easy management, the Ubiquiti UniFi Dream Machine is an excellent choice for anyone looking to establish a reliable and secure network in their home or small office environment.
