Ubiquiti UniFi Gateway Max (UXG-Max)

The Ubiquiti UniFi Next-Gen Gateway Max (UXG-Max) is a powerful, multi-WAN gateway designed for small to medium-sized businesses that require advanced performance, security, and high-speed connectivity in a compact form factor. Engineered for seamless integration within the UniFi Network ecosystem, the UXG-Max combines flexible multi-gigabit ports with enterprise-grade security and modern routing capabilities—making it an ideal choice for growing networks.

At its core, the UXG-Max is powered by a quad-core ARM Cortex-A53 processor running at 1.5 GHz and supported by 2 GB of DDR4 memory. This configuration delivers up to 2.3 Gbps of routing throughput with IDS/IPS enabled, ensuring users can enjoy robust threat protection without compromising performance. Whether handling heavy bandwidth use, VPN traffic, or simultaneous WAN connections, the UXG-Max is built to keep up.

The gateway offers a rich set of physical interfaces including one 2.5GbE WAN port and four 2.5GbE LAN ports, one of which is remappable to act as a second WAN port. This enables multi-WAN configurations for link balancing or failover setups, giving businesses greater uptime and traffic control. Its full 2.5G capability across all ports ensures compatibility with the latest UniFi switches and access points, delivering end-to-end multi-gigabit performance.

The UXG-Max has a compact desktop form factor, making it suitable for wall mounting, shelf placement, or integration into small networking cabinets. It is powered via USB-C (power adapter included), and its fanless design ensures silent operation—a perfect fit for quiet environments like offices, clinics, studios, and co-working spaces.

Security is a core focus of the UXG-Max. It supports a full suite of modern features including stateful firewalling, Layer 7 application-aware firewall, deep packet inspection (DPI), content filtering, intrusion detection and prevention (IDS/IPS), ad blocking, and zone-based network segmentation. These capabilities allow administrators to enforce robust access control policies and safeguard the network from internal and external threats.

The device is managed via UniFi Network (version 8.1.113 or later), with full compatibility for Cloud Key, UniFi Hosting, and UniFi Network Server deployments. Through the intuitive UniFi dashboard, users can manage firewall rules, monitor live traffic, configure VLANs, set up VPNs, and view detailed analytics—all from a centralized interface.

In summary, the Ubiquiti UniFi Next-Gen Gateway Max (UXG-Max) delivers high-performance routing, flexible multi-WAN support, and advanced security features in a sleek, compact form. It’s the ideal choice for small and mid-sized organizations that demand enterprise-grade performance without the complexity or footprint of traditional rackmount gear.
