MikroTik Chateau LTE6

Introducing the D53G-5HacD2HnD-TC&FG621-EA, a cutting-edge wireless router designed for unparalleled performance in demanding network environments. Powered by a robust ARM 32-bit architecture with a quad-core IPQ-4019 CPU, this router delivers exceptional processing power at a nominal frequency ranging from 448 to 896 MHz (auto).

Equipped with 256 MB of RAM and 16 MB of FLASH storage, the D53G-5HacD2HnD-TC&FG621-EA ensures efficient operation and reliable storage for network configurations. The inclusion of IPsec hardware acceleration enhances network security, providing a secure communication environment for your data.

Operating on RouterOS v7 with a RouterOS license for up to 4 devices, this router offers advanced features and customization options. Its tested ambient temperature range of -40°C to 70°C, along with a Mean Time Between Failures (MTBF) of approximately 200,000 hours at 25°C, makes it a reliable solution for challenging environmental conditions.

The D53G-5HacD2HnD-TC&FG621-EA supports a broad range of wireless capabilities. In the 2.4 GHz band, it achieves a maximum data rate of 300 Mbit/s with two chains, adhering to 802.11b/g/n standards. The 2.4 GHz wireless chip model, IPQ-4019, ensures efficient communication, and it operates on Wi-Fi 4 technology.

In the 5 GHz band, the router achieves a maximum data rate of 867 Mbit/s with two chains, complying with 802.11a/n/ac standards. The 5 GHz wireless chip model, also IPQ-4019, operates on Wi-Fi 5 technology, providing high-speed and reliable connectivity. The overall WiFi speed is AC1200, ensuring a seamless and fast user experience.

For mobile connectivity, the D53G-5HacD2HnD-TC&FG621-EA supports 3G Category R8 and LTE Category 6, featuring 2x2 MIMO DL for enhanced performance. It covers various LTE FDD and TDD bands, ensuring compatibility with different networks.

With five 10/100/1000 Ethernet ports, one Micro SIM slot for modems, and one USB port with power reset functionality, this router offers versatile connectivity options. The DC jack input voltage ranges from 12 to 28 V, providing flexibility in powering options. The router has a maximum power consumption of 21 W, with passive cooling ensuring reliability.

Certified with CE, EAC, and ROHS, and boasting an IP20 rating, the D53G-5HacD2HnD-TC&FG621-EA meets industry standards for quality and environmental considerations. Additionally, it features a mode button for convenient control and customization.

In conclusion, the D53G-5HacD2HnD-TC&FG621-EA stands as a powerful and versatile solution for diverse networking applications, combining advanced hardware, robust connectivity options, and enhanced security features to meet the demands of modern networks.
